1 |
Power Supply Requirement: |
400/ 440 V, 3 Phase 50 Hz, 30 KVA |
|
2 |
Tube Unite : |
BEL/ TOSHIBA Rotating Anode Tube Unite with DRA - 1
Tube insert focal spot 1.2 and 2.0 sq. mm. |
|
3 |
Column Stand : |
Floor to Ceiling Stand and with counter
balanced Tube Head , 360 degree rotatable ,
mounted on floor to ceiling rails for
Convenient movements. |
|
4 |
Table : |
Fixed table with Bucky Assly. |
|
5 |
HV Transformer : |
Compact Heavy Duty transformer comprising
HV Silicon Rectifiers, HT Transformer,
Federal Bushing all immersed in Oil. |
|
6 |
300 ma X-ray Generator : |
300 mA, 100 KVP Full Wave Rectified HV
Generator for Radiography |
|
7 |
Rating : |
|
|
|
Small Focus : |
50 mA - 40 - 100 KVP
100 mA - 40 - 100 KVP |
|
|
Large Focus : |
200 mA - 40 - 100 KVP
300 mA - 40 - 100 KVP |
|
8 |
Accessories : |
Hand switch with Flexible long cord
enables to operator to keep from the
Radiation area during exposure
Compression Belt.
Aluminum Filters 0.5 mm and 1 mm
light Beam Diphragm. |
